Main technical parameter:
Item No. |
WN2 |
||
Input |
Voltage |
176VAC~264VAC single phase |
100VAC~120VAC single phase |
Frequency |
50Hz |
60Hz |
|
Current |
5A |
10A |
|
Power |
1000W |
|
|
Output |
Voltage |
Peak 430V |
|
Current |
Peak 200A to 400A |
||
Power |
800W |
||
Storage energy capacitor |
10000-30000uf/450V |
||
Work current(max) |
Average 4A, 5A,peak 20A |
||
Adjust of output voltage |
20 grades, linear regulation |
||
Protection |
Water flow protection, temperature protection |
||
Temperature |
20℃~30℃ |
||
Humidity |
Less than 80% |
||
External dimension |
230*165*116mm (L*W*H) |
||
Run mode |
Intermittent loading continuous run mode, it is better that intermit for 10 minutes every 1000 impulses output that intermit for ten minutes every 1000 impulses output. |
