- Input voltage：220V/110V
- Output power：80W
- Output voltage(Max)：35KV
- Output current(Max)：30mA
Main features:
Input voltage: AC 220V±10%;AC 110V(be ordered)
Max. output voltage: DC 35KV
Max. output current: DC 30mA
Response time: ≤1ms
Work temperature: -10~40°C
Humidity: ≤85%
Laser power regulation: 1.Control the output current of the laser power supply by potentiometer; 2.Controlled by PWM(TTL level)
The laser swtich: Controlled by button or optical coupler interface.
Warranty time: One year
Outside size: 210mm*160mm*95mm
Weight: 3.6KG
We have other specifications to choose:
|
40W CO2 |
60W CO2 |
80W CO2 |
|
|
Model Number |
WJE1-40W |
WJE1-60W |
WJE1-80W |
|
Input Voltage |
220V, 110V(options) |
220V, 110V(options) |
220V, 110V(options) |
|
Output Laser Power |
40W |
60W |
80W |
|
Output Current |
DC 28mA(max) |
DC 28mA(max) |
DC 30mA(max) |
|
Output Voltage |
DC 30KV(max) |
DC 30KV(max) |
DC 35KV(max) |
|
Response Time |
≤1mS |
≤1mS |
≤1mS |
|
Optocoupler Interface Control |
DC(5±2V) |
DC(5±2V) |
DC(5±2V) |
|
Work Temperature |
-10~40℃ |
-10~40℃ |
-10~40℃ |
|
Humidity |
≤85% |
≤85% |
≤85% |
|
Cooling |
air cooling |
air cooling |
air cooling |
|
Dimension |
210*160*95(mm) |
210*160*95(mm) |
210*160*95(mm) |
|
Install Size |
60*48(mm) |
60*48(mm) |
60*48(mm) |
|
Application |
laser cutting, engraving, welding, marking, etc.. |
||
