- Input voltage：380V
- Output power：20KW
- Output voltage(Max)：1KV
- Output current(Max)：400A
- Adjustable：Yes
- Custom：Yes
- Cooling mode：Air cooling
Main technical parameters:
|
Type |
Input Power |
Maximum Current |
Volume(mm) |
Cooling Method |
|
WT2 |
2KW |
2A |
400*95*370 |
Wind |
|
WT5 |
5KW |
6A |
480*135*480 |
Wind |
|
WT10 |
10KW |
12A |
480*135*480 |
Wind |
|
WT20 |
20KW |
26A |
480*135*480 |
Water |
|
WT40 |
40KW |
50A |
600*230*600 |
Water |
|
WT60 |
60KW |
75A |
600*230*600 |
Water |
|
WT80 |
80KW |
100A |
600*460*600 |
Water |
|
WT100 |
100KW |
125A |
600*460*600 |
Water |
Main features:
1.input voltage: AC380V
2.output power:20kw
3.output voltage:200v-1000v
4.output current:0~26A
5.deminsin:L480*H150*W480MM
6.installation size:460*70mm (Embedded Installation)
7.cooling method:water cooling
control method:
1, use the control board of the power, the board could display all the parameters
2, External analog control, control by external 0~5V analog voltage.
3,External digital communication control. RS232,485 or Optical control.
