- Input voltage：380V
- Output power：60KW
- Output voltage(Max)：10KV
- Output current(Max)：10A
- Output frequency：25KHz
- Custom：Yes
Technical Specification
|
Items No. |
WZP60-60KW |
|
Input Voltage |
AC380±10%V |
|
Output Power |
60KW |
|
Output Current |
0~75A |
|
OutputVoltage |
Work voltage 200~800V, no-load>1KV |
|
OutputWave form |
Quasi-sine-wave |
|
OutputMode |
Constant voltage / constant current / constant power |
|
Regulation Precision |
≤1% |
|
Efficiency |
≥90% |
|
Power Factor |
cosΦ≥0.9 |
|
Display Mode |
Chinese, English LCD display |
|
Communication Mode |
CNC / Analog / RS485 / RS232 |
|
Output Protection |
Output overvoltage / output overcurrent / output offset |
|
Input Protection |
Output overvoltage / output undervoltage / input overcurrent / open phase |
|
Safety Protection |
Grounding protection / leakage protection / external control protection / lightning protection / overheating |
|
Insulation Class |
B |
|
Protect Grade |
IP20 |
|
Protection Response Time |
1uS |
|
Temperature |
0~35℃ |
|
Humidity |
≤80% |
|
Cooling mode |
1~10kw air-cooled; 10kw~100kw water-cooled |
|
Dimensions |
600*230*600 (mm) |
|
Net Weight |
40.0kg |
